Non-Removable Pin Hinges




Choose your tip style

1. Button tips
2. Ball tips
3. Urn tips
4. Steeple tips
(All tips are threaded and removable.)



Materials used

Hinges: Solid extruded brass
Pins: Stainless steel
Tips: Solid extruded brass

Finishes

Polished brass (lacquered)
Polished brass (unlacquered)



Size Open
Length x Width		 4½" x 4½" 4" x 4"
Metal thickness 0.134" 0.130"
Knuckle diameter 0.500" 0.500"
Number of holes 8 8
Wood screw size 12 x 1¼" 12 x 1¼"

Other sizes available through special order.
